Deck layout A with optionals
Deck layout B with optionals
A cabin version with optionals
B cabin version with optionals
C cabin version with optionals
Description | Data | ||
---|---|---|---|
Length overall: | 14,86 m / 48’74” | ||
Water line length: | 13,40 m / 43’95” | ||
Beam: | 4,87 m / 15’97” | ||
Draft: | 1,05 m / 3’44” | ||
Approx. light displacement: | 14.750 kg / 32,518 lbs | ||
Approx. load displacement: | 17.550 kg / 38,691 lbs | ||
Fuel capacity: | 1.500 L / 396 US gal | ||
Water capacity: | 430 L / 114 US gal | ||
Diesel Engines: | 2 x Volvo Penta D6 IPS 600 320 kW / 435 hp 3.500 rpm |
||
Diesel Engines (Optional): | 2 x Volvo Penta D6 IPS 650 353 kW / 480 hp 3.800 rpm | 2 x Volvo Penta D8 IPS 800 441 kW / 600 hp 3.000 rpm |
|
Max speed: | 30 kn - IPS 600 | 32 kn - IPS 650 | 37 kn - IPS 800 |
Cruising speed: | 21 kn - IPS 600 | 23 kn - IPS 650 | 27 kn - IPS 800 |
Cabins: | 1/2 | ||
Bathrooms: | 2 | ||
Max persons capacity: | 12 | ||
Design: | Brunello Acampora / Victory Design - Cav. Norberto Ferretti - Solaris Power Design Team | ||
Solaris Power reserves the right to change specifications without notice. |
Engines [RPM] | Speed [Kn] | Fuel [litres / hour] | Fuel [litres / mile] | Range [miles] |
---|---|---|---|---|
600 | 4 | 2,9 | 0,72 | 2.069 |
1000 | 6,5 | 7,5 | 1,15 | 1.300 |
1550 | 9,5 | 20 | 2,10 | 405 |
2000 | 11,9 | 44 | 3,69 | 343 |
2500 | 17,4 | 76 | 4,36 | 336 |
2800 | 21,3 | 95 | 4,46 | 305 |
3000 | 23,2 | 114 | 4,91 | 310 |
3200 | 25,5 | 123 | 4,82 | 305 |
3400 | 28 | 146 | 5,21 | 287 |
3770 | 33 | 190 | 5,75 | 260 |
TEST CONDITIONS - Displacement: 15.980 Kg - Fuel: 1.070 L - Water: 470 L - Crew: 11 people - Atmospheric temp.: 28° - Salt water temp.: 25° |
