Deck layout with optionals
A cabin version with optionals
B cabin version with optionals
C cabin version with optionals
| Description | Data | ||
|---|---|---|---|
| Length overall: | 14,86 m / 48’74” | ||
| Water line length: | 13,40 m / 43’95” | ||
| Beam: | 4,87 m / 15’97” | ||
| Draft: | 1,05 m / 3’44” | ||
| Approx. light displacement: | 14.000 kg / 30,864 lbs | ||
| Approx. load displacement: | 16.800 kg / 37,037 lbs | ||
| Fuel capacity: | 1.500 L / 396 US gal | ||
| Water capacity: | 430 L / 114 US gal | ||
| Diesel Engines: | 2 x Volvo Penta D6 IPS 600 320 kW / 435 hp 3.500 rpm |
||
| Diesel Engines (Optional): | 2 x Volvo Penta D6 IPS 650 353 kW / 480 hp 3.800 rpm | 2 x Volvo Penta D8 IPS 800 441 kW / 600 hp 3.000 rpm |
|
| Max speed: | 32 kn – IPS 600 | 34 kn – IPS 650 | 39 kn – IPS 800 |
| Cruising speed: | 23 kn – IPS 600 | 25 kn – IPS 650 | 29 kn – IPS 800 |
| Cabins: | 1/2 | ||
| Bathrooms: | 1 | ||
| Max persons capacity: | 12 | ||
| Design: | Brunello Acampora / Victory Design – Cav. Norberto Ferretti – Solaris Power Design Team | ||
| Solaris Power reserves the right to change specifications without notice. | |||
| Engines [RPM] | Speed [Kn] | Fuel [litres / hour] | Fuel [litres / mile] | Range [miles] |
|---|---|---|---|---|
| 600 | 4 | 2,9 | 0,72 | 2.069 |
| 1000 | 6,5 | 7,5 | 1,15 | 1.300 |
| 1550 | 9,5 | 20 | 2,10 | 405 |
| 2000 | 11,9 | 44 | 3,69 | 343 |
| 2500 | 17,4 | 76 | 4,36 | 336 |
| 2800 | 21,3 | 95 | 4,46 | 305 |
| 3000 | 23,2 | 114 | 4,91 | 310 |
| 3200 | 25,5 | 123 | 4,82 | 305 |
| 3400 | 28 | 146 | 5,21 | 287 |
| 3770 | 33 | 190 | 5,75 | 260 |
| TEST CONDITIONS – Displacement: 15.980 Kg – Fuel: 1.070 L – Water: 470 L – Crew: 11 people – Atmospheric temp.: 28° – Salt water temp.: 25° | ||||
